Borika Fasten Liimitav platvorm kindlal alusel (110x110)

Paigalduskomplekt kõigi FASTen® lisatarvikute ja -seadmete kiireks ja lihtsaks paigaldamiseks igasugustele kõvadele pindadele.


Süsteem on ette nähtud 12-harulise tähe kujuga isasadapteritega varustatud tarvikute paigaldamiseks anuma kõvale, tasasele ja siledale pinnale (alumiinium, klaaskiud ja lamineeritud puit). Koosneb Fs219 kinnitusest ja kinnitusalusest (110 x 110 mm), mille põhi on kaetud 3M VHB teibiga. Kinnitus sisaldab emast adapterit. Kinnitatakse padja külge nelja M6*20 DIN 912 kruvi ja nelja M6 DIN 934 mutriga. Lisaseadme adapter sisestatakse lõpuni kinnitusse, mille fiksaator on avatud asendis (UNLOCK), seejärel suletakse hoidik (LOCK), kinnitades sellega 7 adapteri hammast 12-st. Kinnituse disain pakub kaitsepistikut. Põhiosad on valmistatud klaaskiuga tugevdatud polüamiidist, padi on kaetud PVC-ga ja varustatud 3M VHB teibiga (110 x 110 mm, paksus — 1,1 mm). Kaitsekork on valmistatud PVC-st. Kinnitused — A2 (AISI 304) roostevaba teras.

The system is designed for mounting accessories provided with male adapters shaped as a 12 pointed star on hard, flat, smooth surfaces of vessel (aluminum, fiberglass and laminated wood). Consists of an Fs219 mount and a mounting pad (110 x 110 mm), the base of which is covered with 3M VHB tape. The mount comprises a female adapter. Attached to the pad with four M6*20 DIN 912 screws and four M6 DIN 934 nuts. The adapter of the accessory is inserted all the way into the mount, the retainer of which is in open position (UNLOCK), then the retainer is closed (LOCK), thus clamping 7 out of 12 adapter teeth. The mount design provides a protective plug. The main parts are made of fiberglass-reinforced polyamide, the pad is covered with PVC and equipped with 3M VHB tape (110 x 110 mm, thickness — 1.1 mm). The protective plug is made of PVC. Fasteners — A2 (AISI 304) stainless steel.
